EQUAL TEE
EQUAL TEE: Confection, unlike injection, means special production by cutting the pipes and joining them with butt welding method with special equipment and tools, not with injection machines. The term “equal” means that all the outlets of the T have the same diameter. It is used to get the same diameter outlet from the main line. It is welded to the system by butt welding or using a suitable EF additional piece. It is suitable for water lines.
| SIRA | ÜRÜN KODU | ÇAP d [mm] | BASINÇ [bar] | L [mm] | L1 [mm] | z [mm] | e [mm] | AĞIRLIK [kg] | KOLİ ADEDİ | KOLİ EBATI |
|---|---|---|---|---|---|---|---|---|---|---|
| SEQ | PRODUCT CODE | SIZE d [mm] | PRESSURE [bar] | L [mm] | L1 [mm] | z [mm] | e [mm] | WEIGHT [kg] | IN A PARCEL | PCS PRICE |
| 1 | 975638700090 | 90*90 | PN10 | 400 | 200 | 245 | 5.4 | 0.88 | 16 | 41/60/31 |
| 2 | 975638100090 | 90*90 | PN16 | 400 | 200 | 245 | 8.2 | 1.27 | 16 | 41/60/31 |
| 3 | 975638700110 | 110*110 | PN10 | 400 | 200 | 255 | 6.6 | 1.3 | 14 | 41/60/46 |
| 4 | 975638100110 | 110*110 | PN16 | 400 | 200 | 255 | 10 | 1.88 | 14 | 41/60/46 |
| 5 | 975638700125 | 125*125 | PN10 | 400 | 200 | 262.5 | 7.4 | 1.65 | 8 | 41/60/46 |
| 6 | 975638100125 | 125*125 | PN16 | 400 | 200 | 262.5 | 11.4 | 2.45 | 8 | 41/60/46 |
| 7 | 975638700140 | 140*140 | PN10 | 526.67 | 263.33 | 343.33 | 8.3 | 2.73 | 8 | 41/60/46 |
| 8 | 975638100140 | 140*140 | PN16 | 526.67 | 263.33 | 343.33 | 12.7 | 4.01 | 8 | 41/60/46 |
| 9 | 975638700160 | 160*160 | PN10 | 546.67 | 273.33 | 353.33 | 9.5 | 3.71 | 6 | 50/60/50 |
| 10 | 975638100160 | 160*160 | PN16 | 546.67 | 273.33 | 353.33 | 14.6 | 5.47 | 6 | 50/60/50 |
| 11 | 975638700180 | 180*180 | PN10 | 600 | 300 | 390 | 10.7 | 5.14 | 4 | 50/60/50 |
| 12 | 975638100180 | 180*180 | PN16 | 600 | 300 | 390 | 16.4 | 7.58 | 4 | 50/60/50 |
| 13 | 975638700200 | 200*200 | PN10 | 600 | 300 | 400 | 11.9 | 6.35 | 2 | 50/60/50 |
| 14 | 975638100200 | 200*200 | PN16 | 600 | 300 | 400 | 18.2 | 9.36 | 2 | 50/60/50 |
| 15 | 975638700225 | 225*225 | PN10 | 640 | 320 | 422.5 | 13.4 | 8.57 | 2 | 50/60/50 |
| 16 | 975638100225 | 225*225 | PN16 | 640 | 320 | 422.5 | 20.5 | 12.58 | 2 | 50/60/50 |
| 17 | 975638700250 | 250*250 | PN10 | 640 | 320 | 435 | 14.8 | 10.56 | - | - |
| 18 | 975638100250 | 250*250 | PN16 | 640 | 320 | 435 | 22.7 | 15.55 | - | - |
| 19 | 975638700280 | 280*280 | PN10 | 680 | 340 | 456.67 | 16.6 | 13.97 | - | - |
| 20 | 975638100280 | 280*280 | PN16 | 680 | 340 | 456.67 | 25.4 | 20.71 | - | - |
| 21 | 975638700315 | 315*315 | PN10 | 800 | 400 | 500.83 | 18.7 | 20.88 | - | - |
| 22 | 975638100315 | 315*315 | PN16 | 800 | 400 | 500.83 | 28.6 | 30.72 | - | - |
| 23 | 975638700355 | 355*355 | PN10 | 866.67 | 433.33 | 577.5 | 21.1 | 28.73 | - | - |
| 24 | 975638100355 | 355*355 | PN16 | 866.67 | 433.33 | 577.5 | 32.2 | 42.25 | - | - |
| 25 | 975638700400 | 400*400 | PN10 | 933.33 | 466.67 | 666.67 | 23.7 | 39.2 | - | - |
| 26 | 975638100400 | 400*400 | PN16 | 933.33 | 466.67 | 666.67 | 36.3 | 57.82 | - | - |
| 27 | 975638700450 | 450*450 | PN10 | 1000 | 500 | 725 | 26.7 | 53.1 | - | - |
| 28 | 975638100450 | 450*450 | PN16 | 1000 | 500 | 725 | 40.9 | 78.45 | - | - |
| 29 | 975638700500 | 500*500 | PN10 | 1106.67 | 553.33 | 803.33 | 29.7 | 72.71 | - | - |
| 30 | 975638100500 | 500*500 | PN16 | 1106.67 | 553.33 | 803.33 | 45.4 | 107.07 | - | - |
| 31 | 975638700560 | 560*560 | PN10 | 1200 | 600 | 880 | 33.2 | 98.64 | - | - |
| 32 | 975638100560 | 560*560 | PN16 | 1200 | 600 | 880 | 50.8 | 145.44 | - | - |
| 33 | 975638700630 | 630*630 | PN10 | 1280 | 640 | 955 | 37.4 | 133.25 | - | - |
| 34 | 975638100630 | 630*630 | PN16 | 1280 | 640 | 955 | 57.2 | 195.84 | - | - |
| 35 | 975638700710 | 710*710 | PN10 | 1400 | 700 | 1055 | 42.1 | 185.01 | - | - |
| 36 | 975638100710 | 710*710 | PN16 | 1400 | 700 | 1055 | 64.5 | 273 | - | - |
| 37 | 975638700800 | 800*800 | PN10 | 1506.67 | 753.33 | 1153.33 | 47.4 | 253.12 | - | - |
| 38 | 975638100800 | 800*800 | PN16 | 1506.67 | 753.33 | 1153.33 | 72.8 | 381.94 | - | - |
| 39 | 975638700900 | 900*900 | PN10 | 1706.67 | 853.33 | 1303.33 | 53.3 | 360.96 | - | - |
| 40 | 975638100900 | 900*900 | PN16 | 1706.67 | 853.33 | 1303.33 | 81.7 | 537.6 | - | - |
| 41 | 975638701000 | 1000*1000 | PN10 | 1773.33 | 886.67 | 1386.67 | 59.3 | 465.5 | - | - |
| 42 | 975638101000 | 1000*1000 | PN16 | 1773.33 | 886.67 | 1386.67 | 90.8 | 688.94 | - | - |
| 43 | 975638701200 | 1200*1200 | PN10 | 2300 | 1150 | 1750 | 70.6 | 879.75 | - | - |
| 44 | 975638101200 | 1200*1200 | PN16 | 2300 | 1150 | 1750 | - | - | - | - |
| 45 | 975638701400 | 1400*1400 | PN10 | 2566.67 | 1283.33 | 1983.33 | 83 | 1328.25 | - | - |
| 46 | 975638101400 | 1400*1400 | PN16 | 2566.67 | 1283.33 | 1983.33 | - | - | - | - |
| 47 | 975638701600 | 1600*1600 | PN10 | 2833.33 | 1416.67 | 2216.67 | 94.8 | 1925.25 | - | - |
| 48 | 975638101600 | 1600*1600 | PN16 | 2833.33 | 1416.67 | 2216.67 | - | - | - | - |
