ELBOW °30
ELBOW 30°: Confection, unlike injection, means special production by cutting pipes and joining them with butt welding method with special equipment and tools, not with injection machines. 30° Elbows are a connection element used to make 30° direction change in pipelines. It is welded to the system by butt welding or using a suitable EF additional piece. It is suitable for water lines.
| SIRA | ÜRÜN KODU | ÇAP d [mm] | BASINÇ [bar] | L [mm] | e [mm] | AĞIRLIK [kg] | KOLİ ADEDİ | KOLİ EBATI |
|---|---|---|---|---|---|---|---|---|
| SEQ | PRODUCT CODE | SIZE d [mm] | PRESSURE [bar] | L [mm] | e [mm] | WEIGHT [kg] | IN A PARCEL | PCS PRICE |
| 1 | 975633700090 | 90 | PN10 | 140 | 5.4 | 0.41 | - | - |
| 2 | 975633100090 | 90 | PN16 | 140 | 5.4 | 0.41 | - | - |
| 3 | 975633700110 | 110 | PN10 | 140 | 6.6 | 0.61 | - | - |
| 4 | 975633100110 | 110 | PN16 | 140 | 6.6 | 0.61 | - | - |
| 5 | 975633700125 | 125 | PN10 | 150 | 7.4 | 0.83 | - | - |
| 6 | 975633100125 | 125 | PN16 | 150 | 7.4 | 0.83 | - | - |
| 7 | 975633700140 | 140 | PN10 | 160 | 8.3 | 1.11 | - | - |
| 8 | 975633100140 | 140 | PN16 | 160 | 8.3 | 1.11 | - | - |
| 9 | 975633700160 | 160 | PN10 | 170 | 9.5 | 1.54 | - | - |
| 10 | 975633100160 | 160 | PN16 | 170 | 9.5 | 1.54 | - | - |
| 11 | 975633700180 | 180 | PN10 | 180 | 10.7 | 2.06 | - | - |
| 12 | 975633100180 | 180 | PN16 | 180 | 10.7 | 2.06 | - | - |
| 13 | 975633700200 | 200 | PN10 | 190 | 11.9 | 2.68 | - | - |
| 14 | 975633100200 | 200 | PN16 | 190 | 11.9 | 2.68 | - | - |
| 15 | 975633700225 | 225 | PN10 | 200 | 13.4 | 3.57 | - | - |
| 16 | 975633100225 | 225 | PN16 | 200 | 13.4 | 3.57 | - | - |
| 17 | 975633700250 | 250 | PN10 | 210 | 14.8 | 4.62 | - | - |
| 18 | 975633100250 | 250 | PN16 | 210 | 14.8 | 4.62 | - | - |
| 19 | 975633700280 | 280 | PN10 | 220 | 16.6 | 6.03 | - | - |
| 20 | 975633100280 | 280 | PN16 | 220 | 16.6 | 6.03 | - | - |
| 21 | 975633700315 | 315 | PN10 | 230 | 18.7 | 8 | - | - |
| 22 | 975633100315 | 315 | PN16 | 230 | 18.7 | 8 | - | - |
| 23 | 975633700355 | 355 | PN10 | 240 | 21.1 | 10.61 | - | - |
| 24 | 975633100355 | 355 | PN16 | 240 | 21.1 | 10.61 | - | - |
| 25 | 975633700400 | 400 | PN10 | 250 | 23.7 | 14 | - | - |
| 26 | 975633100400 | 400 | PN16 | 250 | 23.7 | 14 | - | - |
| 27 | 975633700450 | 450 | PN10 | 260 | 26.7 | 18.41 | - | - |
| 28 | 975633100450 | 450 | PN16 | 260 | 26.7 | 18.41 | - | - |
| 29 | 975633700500 | 500 | PN10 | 270 | 29.7 | 23.65 | - | - |
| 30 | 975633100500 | 500 | PN16 | 270 | 29.7 | 23.65 | - | - |
| 31 | 975633700560 | 560 | PN10 | 280 | 33.2 | 30.69 | - | - |
| 32 | 975633100560 | 560 | PN16 | 280 | 33.2 | 30.69 | - | - |
| 33 | 975633700630 | 630 | PN10 | 320 | 37.4 | 44.42 | - | - |
| 34 | 975633100630 | 630 | PN16 | 320 | 37.4 | 44.42 | - | - |
| 35 | 975633700710 | 710 | PN10 | 340 | 42.1 | 59.91 | - | - |
| 36 | 975633100710 | 710 | PN16 | 340 | 42.1 | 59.91 | - | - |
| 37 | 975633700800 | 800 | PN10 | 370 | 47.4 | 82.88 | - | - |
| 38 | 975633100800 | 800 | PN16 | 370 | 47.4 | 82.88 | - | - |
| 39 | 975633700900 | 900 | PN10 | 390 | 53.3 | 109.98 | - | - |
| 40 | 975633100900 | 900 | PN16 | 390 | 53.3 | 109.98 | - | - |
| 41 | 975633701000 | 1000 | PN10 | 420 | 59.3 | 147 | - | - |
| 42 | 975633101000 | 1000 | PN16 | 420 | 59.3 | 147 | - | - |
| 43 | 975633701200 | 1200 | PN10 | 550 | 70.6 | 280.5 | - | - |
| 44 | 975633101200 | 1200 | PN16 | 550 | 70.6 | 280.5 | - | - |
| 45 | 975633701400 | 1400 | PN10 | 600 | 83 | 414 | - | - |
| 46 | 975633101400 | 1400 | PN16 | 600 | 83 | 414 | - | - |
| 47 | 975633701600 | 1600 | PN10 | 700 | 94.8 | 634.2 | - | - |
| 48 | 975633101600 | 1600 | PN16 | 700 | 94.8 | 634.2 | - | - |
